TR9308A can measure voltages up to 8KV DC and 6KV AC, with an input impedance of 100MΩ and low load effect, while the 40MHz high bandwidth allows you to capture fast, high-voltage signals. The high-voltage probe can be connected to an oscilloscope for direct measurement, which is suitable for high-voltage grounding reference voltage measurement. In addition, an optional adapter can measure the voltage value on the digital meter. TR9308A the use of environmentally friendly silicone insulating media can increase the insulation performance, ensure that the internal components do not oxidize when measuring high voltages, and extend the service life.

Features:
• Maximum voltage measurement: 8KV DC+ACpeak
• Bandwidth up to 40MHz
• Input impedance 100MΩ
• Fixed attenuation ratio of 1:1000
• Can be connected to a multimeter with an impedance matcher
